A Philippine Cut to Fall Roof is always as individual as the flat roof for which it is made. In this way, all relevant information flows into the production of the Cut to Fall Panels and the Philippine Cut to Fall Roof is optimally fitted to the respective property.

Flat Roof Insulation Panels

symbole

Dimensions/mm (standard): Gross dimension 1000 x 1000

(Net Dimension 985 x 985) other formats on request
Packaging: PE foil free of charge

PH-FLD 100/040 DAA dm

pdf downloadWLG 040 dm | Compressive Strength ≥ 100 kPa
Boards with shiplapped edges or optionally with smooth edges

Thermal Conductivity 0,040 W/mK
Field of use according to DIN 4108-10 DAA dm
Reaction to Fire according to DIN EN 13501, Euroclass E
Application area: Insulation of flat roofs

PH-FLD 150/035 DAA dh

pdf downloadWLG 035 dh | Compressive Strength ≥ 150 kPa
Boards with shiplapped edges or optionally with smooth edges

Thermal Conductivity 0,035 W/mK
Field of use according to DIN 4108-10 DAA dh
Reaction to Fire according to DIN EN 13501, Euroclass E
Application area: Insulation of flat roofs

Flat Roof Insulation Panels

symbole

Dimensions/mm (standard): Gross dimension 1000 x 1000

(Net Dimension 985 x 985) other formats on request
Packaging: PE foil free of charge

PH-FLD 100/032 DAA dm

pdf downloadWLG 032 dm | Compressive Strength ≥ 100 kPa
Boards with shiplapped edges or optionally with smooth edges

Thermal Conductivity 0,032 W/mK
Field of use according to DIN 4108-10 DAA dm
Reaction to Fire according to DIN EN 13501, Euroclass E
Application area: Insulation of flat roofs

PH-FLD 150/032 DAA dh

pdf downloadWLG 032 dh | Compressive Strength ≥ 150 kPa
Boards with shiplapped edges or optionally with smooth edges

Thermal Conductivity 0,032 W/mK
Field of use according to DIN 4108-10 DAA dh
Reaction to Fire according to DIN EN 13501, Euroclass E
Application area: Insulation of flat roofs

Cut to Fall Insulation Panels

symbole

Packaging: PE foil free of charge

PH-GLD 100/040 DAA dm

pdf downloadCompressive Strength ≥ 100 kPa

Field of use according to DIN 4108-10 DAA dm
Reaction to Fire according to DIN EN 13501, Euroclass E
Individually planned and calculated according to a given measurement sketch.

We only create roof plans when an order is placed.

Color coding of the roofs.

PH-GLD 200/035 DAA ds

pdf downloadCompressive Strength ≥ 200 kPa

Field of use according to DIN 4108-10 DAA ds
Reaction to Fire according to DIN EN 13501, Euroclass E
Individually planned and calculated according to a given measurement sketch.

We only create roof plans when an order is placed.

Color coding of the roofs.

High-Point Pieces

symbole



PH-GLD DRS 100/040 DAA dm

pdf downloadThermal Conductivity 0,040 W/mK
Field of use according to DIN 4108-10 DAA dm
Reaction to Fire according to DIN EN 13501, Euroclass E
Individually planned and calculated according to a given measurement sketch.

We only create roof plans when an order is placed.

Formats D1 – D10

Flat Roof Wedges

symbole

Length / mm: 1000
Packaging: free of charge

PH-FDK 100/040 DAA dm

Compressive Strength ≥ 100 kPa
Length in mm: 1000

Thermal Conductivity 0,040 W/mK
Field of use according to DIN 4108-10 DAA dm
Reaction to Fire according to DIN EN 13501, Euroclass E

Hollow Space Filling

symbole

Packaging: free of charge

PH-HRS

pdf downloadThermal Conductivity 0,035 W/mK

Thermal insulation fill made of polystyrene particle foam granulate for insulating cavities in floors, ceilings and roofs.

It is used in areas that are not subject to pressure.

Reaction to Fire according to DIN EN 13501, Euroclass E
Application area:
Insulation of cavities from ceilings to unheated
 Roof spaces and between rafters of pitched roofs.
